Professional Grade Zinc Phosphate Pigment for High-Performance Anti-Corrosion

Place of Origin HEBEI,CHINA
Brand Name MEIYU
Certification REACH;SGS;ISO9001
Model Number 7779-90-0
Minimum Order Quantity 1 kg
Packaging Details 25kg/bag, Plastic-lined woven bag or Composite paper bag.
Delivery Time 5-8 work days
Payment Terms L/C, T/T
Supply Ability 1000 tons per week

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
CAS No. 7779-90-0 Grade Industrial Grade
Appearance White Powder Industry Paint
1.Application Antirust Paint. Antirust Coating 2.Application Phosphating Treatment Of Steel And Flame Retardant Of Polymer Materials
High Light

7779-90-0 Chemical

,

anti rust zinc phosphate pigment

,

cas no 7779-90-0 zinc phosphate pigment

Leave a Message
Product Description

TECHNICAL PARAMETERS OF ZINC PHOSPHATE:

TEST ITEM O-leve High purity EPMC ZPA
Whiteness % 80-90 805-90 80-90 ≥95
ZP% ≥45 ≥99.5 ≥99.5 ≥93
Moisture % ≤1.5 ≤1.5 ≤1.5 ≤1.5
PH Value 5.5-7 5.5-7 5.5-7 5.5-7
Oil absorption ml/100g 30±5 30±5 30±5 30±5
Residue on sieve 45μm ≤0.5 ≤0.1 ≤0.1 ≤0.1
Cr % -- <0.005 <0.003 <0.003
Pb % -- <0.005 <0.005 <0.01
Standard HG/T4824-2015


Zinc phosphate is widely used as a chemical anti-rust pigment in oily and water-based primers



1.Usage:

Zinc phosphate is an important anti-rust pigment. It is one of the substitutes for lead and chromium anti-rust pigments in the paint industry. It has been used since 1965 and is widely used in oil-based and water-based primers as chemical anti-rust pigments. To improve and improve its anti-rust performance, it is currently the most widely used non-toxic anti-rust pigment. In addition to being environmentally friendly and non-toxic, zinc phosphate also has the following advantages:
White or light color, low refractive index, so it is very easy to color; can be dispersed in various base materials such as oil-based resin and water-based; coatings prepared with it have good construction performance, and can be combined with metal substrates or surface The paint film has strong adhesion.



2.Applications:

Mechanism: Standard zinc phosphate antirust pigment is zinc orthophosphate white powder, mainly dihydrate type (Zn3 (PO4) 2.2H2O) and mixed type of dihydrate and tetrahydrate (Zn3 (PO4) 2.4H2O) . Its anti-rust mechanism is very complicated. The main anti-rust mechanism of zinc orthophosphate pigment:


[Fe(H2O)6] 2+→ [Fe(H2O)5(OH)] ++H+
Zn3(PO4)2+H+→H3PO4 + Zn2+
H3PO4+Fe→Fe(H2PO4)2+H2
Fe(H2PO4)2+H2O→FeHPO4+H3PO4+H2O
FeHPO4+H2O→Fe3(PO4)2+H3PO4+H2O


The dissolved ferrous salt and iron salt are hydrolyzed to release protons, and then gradually react with zinc orthophosphate to sequentially generate water-soluble first-generation ferrous phosphate and second-generation ferrous phosphate, and finally insoluble third-generation ferrous phosphate. Passivation occurs on the surface of the metal substrate to produce Me (metal) -Zn-P2O5, a phosphating film with complex, dense and strong adhesion.
a) In addition to phosphating, they can also react with the carboxyl and hydroxyl groups in the base material and certain ions in the corrosive environment to form complexes, and this complex can react with corrosion products. A tightly adhered protective film is formed on the surface of the material.
b) The anti-rust effect of zinc orthophosphate is mainly due to the presence of crystal water, which slowly hydrolyzes to form zinc hydroxide and zinc diphosphate ions, the latter through the formation of a protective film composed of a complex with adhesive corrosion inhibition And realize anode protection.
c) Zinc orthophosphate slows down the diffusion rate of ammonium ions through the coating film, thereby playing a corrosion inhibitory effect.



3.Zinc phosphate chemical examination report:


Professional Grade Zinc Phosphate Pigment for High-Performance Anti-Corrosion 0

Professional Grade Zinc Phosphate Pigment for High-Performance Anti-Corrosion 1
